Thin led light boxes display , aluminum frame , super slim

Size details for our ultra thin led light box display

Our led light boxes are produced with national standard film sizes like :

A0,A1,A2,A3,A4...

B0,B1,B2,B3,B4...

C0,C1,C2,C3,C4...

Please refer to following international graphic sizes standard chart :

ISO Graphic Size Standard (mm) for Light boxes Film / Media / graphic sizes
A Series		B Series		C Series
A0	841×1189	B0	1000×1414	C0	917×1297
A1	594×841	B1	707×1000	C1	648×917
A2	420×594	B2	500×707	C2	458×648
A3	297×420	B3	353×500	C3	324×458
A4	210×297	B4	250×353	C4	229×324
A5	148×210	B5	176×250	C5	162×229
A6	105×148	B6	125×176	C6	114×162
A7	74×105	B7	88×125	C7	81×114
A8	52×74	B8	62×88	C8	57×81
A9	37×52	B9	44×62	C9	40×57
A10	26×37	B10	31×44	C10	28×40

All the sizes above are printed graphic size for all our aluminum frame led light boxes display products if not specified :

Film Size also called Media Size, graphic size is the dimension for printing ;

Frame Size is the dimension of our whole light boxes ;

Viewable Image Size also called viewing size , visible size is the dimension which can be seen on the light boxes .
(It's useful information for designers, it should take considering all picture and letters should zoom out to this area .
Or probably some graphic content will be covered by aluminum snap frame bars around )

Following are our standard series for this ultra thin light boxes including frame sizes / view-able sizes / film sizes details :

LED Single-Sided Light Boxes - Aluminium Frame Series

Ultra Thin Light Boxes Single Side 13 mm
Model	Frame size /mm		Viewing size /mm	Thickness /mm	Film Size /mm
Model	Frame size /mm		Viewing size /mm	Thickness /mm	Film Size /mm
5L-AF14A	A0	1227x889	1171x833	13	1189x841
	A1	632×889	576×833	13	594x841
	A2	458×642	402×586	13	420x594
	A3	335×468	279×412	13	297x420
	A4	335×468	279×412	13	297x420
